Customized Multi-Stage Hydraulic Cylinder CDH1 MF4 Telescopic Long Stroke Hydraulic Cylinder
CDH1 MF4 custom multi-stage hydraulic cylinder is a telescopic hydraulic actuator designed specifically for long stroke and compact installation space requirements. It adopts a multi section nested structure, which greatly shortens the overall length in the retracted state, and can be extended step by step during operation, achieving a stroke length far exceeding that of a single-stage cylinder. This product is developed based on the CDH1 series platform, and MF4 usually represents a specific installation method, supporting customization of stroke, number of sections, cylinder diameter, pressure rating, and sealing configuration according to customer working conditions. Its high rigidity structure and precision guidance system ensure smooth operation even under heavy or off load conditions, and are widely used in fields such as dump trucks, lifting platforms, agricultural machinery, engineering machinery, and special equipment. It is particularly suitable for application scenarios that require "large travel and small installation space". Through modular design and strict manufacturing processes, the CDH1 MF4 multi-stage hydraulic cylinder ensures reliability while balancing lightweight and long life, making it an ideal customized solution for efficiently solving the problem of long stroke driving.
Technical Specifications
| Application Industries |
Engineering machinery, mining, shipping, metallurgy, water conservancy, offshore, agriculture |
| Seal Brands |
Parker, Merkel, Hallite |
| Paint Colors |
Red, Grey, Yellow, Black, or custom colors |
| Material Options |
St52, CK45, 4140, Duplex2205, Stainless Steel 304/316 |
| Certification |
ABS, Lloyds, SGS |
| Package |
Bubble-wrap packing in wooden case |
| Core Components |
Bearing, Pressure vessel, Pump |
| Structure |
Piston Type, Plunger Type, Telescopic Type |
| Power |
Hydraulic & Pneumatic |
| Brand |
Guoyue |
Industrial Applications
General Industrial Applications
- Plastic Machinery: Ejector mechanisms and core pulling devices in injection molding machines
- Press Fitting Equipment: Bearing press fitting and shaft sleeve assembly operations
- Packaging Machinery: Capping, bundling, and lifting platform functions
- Material Handling: Lifting platforms, flipping mechanisms, and clamping devices
Additional Application Areas
- Machine Tools & Automation: Clamping/releasing actions, workpiece positioning, robot-assisted drive systems
- Light Engineering Machinery: Agricultural equipment, garbage compression systems
- Testing Equipment: Material testing machine loading systems and sealing test clamping cylinders
Certification & Quality
Our hydraulic cylinders meet rigorous quality standards and are certified by leading classification societies including ABS, Lloyds, and SGS.
Support & Services
Our comprehensive technical support includes troubleshooting guidance, maintenance advice, and direct access to specialized engineers. We provide installation assistance, calibration services, and training resources to ensure optimal performance and safe operation.
Packaging & Shipping
Each hydraulic cylinder is carefully packaged in protective materials with clear handling instructions. Units are securely packed in wooden packaging to prevent damage during transportation.
Frequently Asked Questions
| What is the brand name of this Hydraulic Cylinder? |
The brand name of this Hydraulic Cylinder is Guoyue. |
| Where is this Hydraulic Cylinder manufactured? |
This Hydraulic Cylinder is manufactured in China. |
| What type of certification does this Hydraulic Cylinder have? |
This Hydraulic Cylinder is certified with CE. |
| What is the minimum order quantity for this Hydraulic Cylinder? |
The minimum order quantity for this Hydraulic Cylinder is 1. |
| What is the price range for this Hydraulic Cylinder? |
The price range for this Hydraulic Cylinder is between $250 and $500. |
| How is this Hydraulic Cylinder packaged for shipping? |
This Hydraulic Cylinder is packaged in a wooden package. |
| What is the delivery time for this Hydraulic Cylinder? |
The delivery time for this Hydraulic Cylinder is 31 days. |
| What are the payment terms accepted for this Hydraulic Cylinder? |
The accepted payment terms for this Hydraulic Cylinder are T/T and L/C. |
